Anti Leakage Prefabricated Geomembrane Liners Geomembrana Hdpe 40 Mils GM13 GB Standard

Name: Anti Leakage Prefabricated Geomembrane Liners Geomembrana Hdpe 40 Mils GM13 GB Standard
Brand: Wanshengli
Price: 1 USD

China Anti Leakage Prefabricated Geomembrane Liners Geomembrana Hdpe 40 Mils GM13 GB Standard wholesale

Brand Name : Wanshengli

Model Number : 2.0mm

Certification : GM13, GB, ISO,CE

Place of Origin : Luan, China

MOQ : 1000sqm

Price : Negotiable

Payment Terms : L/C, D/P, T/T, Western Union, MoneyGram

Supply Ability : 50000 sqm per day

Delivery Time : As per your quantity

Packaging Details : Plastic bags or as your request

Product material : Polyethylene or HDPE

Product Color : Black white

Packing : Woven plastic bag

Surface : Double smooth, textured, double textured

Length : 50m 100m

Width : 5.8m or your request

Features : Anti-uv Hdpe Pond Liner,aging Resistence,waterproof,UV Resistence

Thickness : 2.0mm

Density : 0.94

Sample : Support

Contact Now

GM13 GB Standard Anti Leakage Geosynthetic Membrane Geomembrane Liner 2.0mm For Landfill Urban Solid Waste Project

Production Description:

Wanshengli Brand geosynthetic membrane HDPE geomembrane is made from 97.5% high density polyethylene (HDPE) and other 2.5% Carbon black/anti-aging agent/anti-oxygen/UV absorbent/stabilizer and other accessory, which is widely used for fishpond, solid waste containment and water containment environment and mining environment. Geosynthetic Membrane HDPE geomembrane is made of best quality high density polyethylene (HDPE) with specially formulated and original polyethylene resin, combined with specified quantity carbon black, antioxidant, anti-aging agent and UV resistance components, which contributes to its excellent resistance to UV radiation and being suitable for different conditions.

Quick Detail:

Material: HDPE
Length: 50-200m & customerize
Width: 1-8m & customized
Thickness: 2.0mm
Production standard: GM13, GB, ISO
Application: Solid Waste Containment & other agriculture, chemical industry, sewage plant

Anti Leakage Prefabricated Geomembrane Liners Geomembrana Hdpe 40 Mils GM13 GB Standard

Product Parameter

Thickness	0.25mm	0.35mm	0.5mm	0.75mm	1.0mm	1.25mm	1.5mm	2.0mm
Density g/m2	≥0.94
Tensile yield strength (N/mm)	3.75	5	7.5	11	15	18	22	29
Tensile breaking strength (N/mm)	6.75	13.5	19	20	27	33	40	53
Elongation at yield(%)	≥12
Elongation at break(%)	≥700
Puncture strength(N)	80	150	160	240	320	400	480	640
Angle tear load	31.25	45	62.5	93	125	160	190	250
Carbon black content(%)	2.0-3.0
85℃ aging after 90 days high pressure	55

Data

Properties		Test				Test Value				Testing Frequency
		Method	30 mils	40 mils	50 mils	60 mils	80 mils	100 mils	120 mils	(minimum)
Thickness (min. ave.)		D5199	nom.	Nom.	Nom.	Nom.	Nom.	Nom.	Nom.	Per roll
Lowest individual of 10 values			-10%	-10%	-10%	-10%	-10%	-10%	-10%
Density mg/l (min.)		D 1505/D 792	0.940 g/cc	0.940 g/cc	0.940 g/cc	0.940 g/cc	0.940 g/cc	0.940 g/cc	0.940 g/cc	200,000 lb
Tensile Properties (1) (min. ave.)		D 6693								20,000 lb
Yield strength		Type IV	63 lb/in.	84 lb/in.	105 lb/in.	126 lb/in.	168 lb/in.	210 lb/in.	252 lb/in.
Break strength			114 lb/in.	152 lb/in.	190 lb/in.	228 lb/in.	304 lb/in.	380 lb/in.	456 lb/in.
Yield elongation			12%	12%	12%	12%	12%	12%	12%
Break elongation			700%	700%	700%	700%	700%	700%	700%
Tear Resistance (min. ave.)		D 1004	21 lb	28 lb	35 lb	42 lb	56 lb	70 lb	84 lb	45,000 lb
Puncture Resistance (min. ave.)		D 4833	54 lb	72 lb	90 lb	108 lb	144 lb	180 lb	216 lb	45,000 lb
Stress Crack Resistance (2)		D5397	300 hr.	300 hr.	300 hr.	300 hr.	300 hr.	300 hr.	300 hr.	per GRI-GM10
(App.)
Carbon Black Content (range)		D 4218 (3)	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	20,000 lb
Carbon Black Dispersion		D 5596	note (4)	note (4)	note (4)	note (4)	note (4)	note (4)	note (4)	45,000 lb
Oxidative Induction Time (OIT) (min. ave.) (5)										200,000 lb
(a)	Standard OIT	D 3895	100 min.	100 min.	100 min.	100 min.	100 min.	100 min.	100 min.
	— or —
(b) High Pressure OIT		D 5885	400 min.	400 min.	400 min.	400 min.	400 min.	400 min.	400 min.
Oven Aging at 85°C (5), (6)		D 5721
(a) Standard OIT (min. ave.) - % retained after 90 days		D 3895	55%	55%	55%	55%	55%	55%	55%	per each
	— or —									formulation
(b) High Pressure OIT (min. ave.) - % retained after 90 days		D 5885	80%	80%	80%	80%	80%	80%	80%
UV Resistance (7)		D 7238
(a) Standard OIT (min. ave.)		D 3895	N.R. (8)	N.R. (8)	N.R. (8)	N.R. (8)	N.R. (8)	N.R. (8)	N.R. (8)	per each
	— or —									formulation
(b) High Pressure OIT (min. ave.) - % retained after 1600 hrs (9)		D 5885	50%	50%	50%	50%	50%	50%	50%

Anti Leakage Prefabricated Geomembrane Liners Geomembrana Hdpe 40 Mils GM13 GB Standard

Package:

Packaging Details:

Neutral package of Pond Liner Material

Roll Size: 4m-5.8m

Or packed according to customers' requirements such as mark the company Logo

As example:

Specification 20ft container 40ft container

0.2mm size: 5.8m*300m 20GP 58rolls 10092 sqm

Anti Leakage Prefabricated Geomembrane Liners Geomembrana Hdpe 40 Mils GM13 GB Standard
